UNIFORM CYLINDER HEATING
180 mm Heater Band
180 mm Heater Band by LICHENGDA. Diameter, width and clamping contact, configuration details and made-to-drawing quotation for extrusion barrels and injection-molding tooling.
Product image gallery (7)
PRODUCT ENGINEERING
Diameter, width and clamping contact
180 mm Heater Band: Match inside diameter and band width to the barrel or nozzle. Contact gaps create local hot spots; the closure, terminal angle and available tightening space belong on the installation drawing.
Review expansion during heating and the equipment maker’s tightening procedure. Keep lead routing outside the hottest zone and confirm sensor placement for each controlled barrel section.
For 180 mm Heater Band, use the listed 180 mm as catalog identifiers and confirm the complete electrical and dimensional combination before calculating current, selecting a supply or fixing the mounting pattern.
The archived configuration for 180 mm Heater Band lists Voltage: 120V, 240V, 480V, 600V and so on; Power: 50-2000W, or customized. Treat these as reference options and reconcile them with the named configuration and installation drawing before quotation.
For 180 mm Heater Band, send the supply, continuous and peak temperature, mounting drawing, lead exit and quantity. Include the heated medium and control method so the quoted configuration can be checked against the actual duty.
| Catalog name values | 180 mm |
|---|
Application and reference configuration
Extrusion barrels and injection-molding tooling. The final suitability of 180 mm Heater Band depends on the assembled equipment and agreed operating conditions.
Archived figures below describe reference options or a product series. Confirm the exact model specification in the quotation.
| Product Name | Ceramic Band Heater |
|---|---|
| Advantage | high working temperature and long usage lifetime |
| Heating Element | Air heater |
| Voltage | 120V, 240V, 480V, 600V and so on |
| Power | 50-2000W, or customized |
ARCHIVED PRODUCT INFORMATION
Description
ceramic band heater is an industrial heating device designed to wrap around cylindrical objects, such as pipes, barrels, or tubes, in order to provide controlled and efficient heating. These heaters are commonly used in various industrial applications where heating of cylindrical surfaces is required, such as plastic processing, packaging, extrusion, and molding.
|
Product Name |
Ceramic Band Heater |
|
Advantage |
high working temperature and long usage lifetime |
|
Heating Element |
Air heater |
|
Voltage |
120V, 240V, 480V, 600V and so on |
|
Power |
50-2000W, or customized |
product features
1.Vottage :380V,240V, 220V,200V,110V and other can be customized.
2.Wattage :80W,100W,200W,250W and other can be customized.
3.Heater Inside Diameter :25mm, 30mm, 40mm, 60mm, 80mm, 100mm and other can be customized.
4.Heater Height :30mm, 40mm, 60mm, 80mm, 100mm and other can be customized.
5.Whether you need holes or not. If yes, it is necessary to provide holes' quantity, size and position.
6.Termination Stype :screw terminal, plug terminal, ceramic block terminal or lead wire terminal.
The key features of a ceramic band heater include:
Ceramic Insulation: The outer shell of the heater is typically made from a ceramic material that provides good electrical insulation and thermal resistance, allowing the heater to reach high temperatures while minimizing heat loss to the surroundings.
Heating Element: The heating element is often made from a resistance wire, such as nichrome, which generates heat when an electric current passes through it. This wire is wound around the ceramic core and is responsible for heating the surface to the desired temperature.
Clamping Mechanism: Ceramic band heaters usually have a clamping mechanism or adjustable straps that allow them to securely attach to the cylindrical object they are heating. This ensures efficient heat transfer and prevents the heater from slipping or moving during operation.
Temperature Control: Many ceramic band heaters come with built-in or external temperature control systems that allow users to regulate the heating output. This ensures precise and consistent temperature control, which is crucial for various industrial processes.
Uniform Heating: The design of ceramic band heaters is such that they provide uniform heating along the entire circumference of the cylindrical object. This even distribution of heat helps prevent hotspots and ensures consistent product quality.
Durability: Ceramic band heaters are designed to withstand rugged industrial environments and can often operate at high temperatures, making them suitable for various applications.
Variety of Sizes: Ceramic band heaters come in various sizes to accommodate different diameters of cylindrical objects. Custom sizes can also be manufactured to meet specific requirements.
It's important to note that while ceramic band heaters are commonly used, other types of band heaters exist as well, such as mica band heaters and mineral-insulated band heaters. The choice of heater type depends on factors such as the intended application, required temperature range, and specific industry needs.
Applications:
1, Plastic processing machinery
2, Injection and blow moulding
3, Hot runner bushings
4.Plastic injection moulding machine
5.Hollow shaping machine/Blow-molding machine
6.Extrusion machine/Co-extrusion line
7.Raw material processing equipment
8.Pelletizing equipment
9.Granular machine
Company profile
1. Qucik Response:Your inquiry will be replied within 24 hours. Response Rate over 90%
2. Smooth Communication: Well-trained and experienced staffs to answer all your inquires.
3. Sincere Service Attitude: Treat Customers As Friends. No Questions are Neglected.
4. OEM Accepted: Free Sample,We can customize your products to meet all your different requests.
5. Small MOQ: Small Amount wholesales are supported to meet your needs as well as large demands.
6. Fast Delivery: We have Reliable Forwarders with long term cooperation and Competitive Price.
You may contact any one of our sales and services team: email to us as inquiry.
Hot Tags: 180 mm heater band, China, manufacturers, suppliers, factory, wholesale, customized, cheap, in stock, free sample, mica band heater industrial electric, extruder mica band heater element, Electric Heater Elements Band Mica Heater, flat mica heater heating element, stainless steel mica band heater 220v, stainless steel mica band heater plate
Specifications and availability vary by configuration. Confirm dimensions, materials and electrical or measurement ratings in your quotation.
